Grouping with namespaces

By default AppSignal uses three namespaces: "web" for web requests, "frontend" for front-end JavaScript and "background" for background jobs. These namespaces are used to group actions for which errors and performance measurements are tracked.

Apps can have more than three of these namespaces, like an Administration panel, API, scheduled tasks, etc. In this guide we will go through the steps needed to report actions in custom namespaces.

Configuring namespaces

Namespaces are set up from within the app code. With small helpers the namespace of an action can be customized. In this guide we will split up requests in an "admin" namespace and "critical" namespace for background jobs. Check the guide for the language your app uses below.

Ruby

In a Rails controller we use a before_action callback to call a method before the request is handled by Rails. In this method we call the Appsignal.set_namespace helper method to configure the namespace for this request. This also works if the AdminController is subclassed by other controllers. All sub-controllers will be part of the "admin" namespace.

# In a Rails controller
# app/controllers/admin_controller.rb
class AdminController < ApplicationController
  before_action :set_appsignal_namespace

  def set_appsignal_namespace
    # Configures all actions in this controller to report
    # in the "admin" namespace
    Appsignal.set_namespace("admin")
  end

  # Any other controller actions
end

In a Sidekiq background worker we'll need to call Appsignal.set_namespace as one of the first things in the worker to make sure it's set before any errors occur.

# In a Sidekiq worker
# app/workers/critical_worker.rb
class CriticalWorker
  include Sidekiq::Worker

  def perform
    # Configures this worker's jobs to report in the "critical" namespace
    Appsignal.set_namespace("critical")

    # The actual worker code
  end
end

It's also possible to configure the namespace when creating the transaction. The second argument of[Appsignal::Transaction.initialize][transaction_initialize] accepts the namespace value.

# When creating a new transaction
transaction = Appsignal::Transaction.create(
  SecureRandom.uuid, # Random transaction ID
  "admin", # Namespace
  Appsignal::Transaction::GenericRequest.new({}) # Default environment object
)

# When changing the namespace later on for a transaction
transaction.set_namespace("slow_admin")

A note on helper location

The set_namespace helpers used in this guide can be called in any action that starts an AppSignal transaction. We recommend calling this as early in the request or background job as possible, so the transaction is configured with the given namespace before any error occurs. Otherwise, if an error occurs—or anything else that stops the process—the transaction is sent to AppSignal before the set_namespace code is called and it is reported under the default namespace instead.

Read more

• Appsignal.set_namespace helper method documentation

Elixir

In a Phoenix controller we use a plug to call a function before the request is handled by Phoenix. In this function we call the Appsignal.Transaction.set_namespace helper to configure the namespace for this request.

# In a Phoenix controller
defmodule AppsignalPhoenixExampleWeb.AdminController do
  use AppsignalPhoenixExampleWeb, :controller

  plug :set_appsignal_namespace

  defp set_appsignal_namespace(conn, _params) do
    # Configures all actions in this controller to report
    # in the "admin" namespace
    Appsignal.Span.set_namespace(Appsignal.Tracer.root_span(), "admin")
    conn
  end

  # ...
end

In a background job call the Appsignal.Transaction.set_namespace at the beginning of the function, before any other code. This ensures that it's configured before any error can occur in the job.

defmodule MyApp.CriticalJob do
  def run do
    # Configures this worker's jobs to report in the "critical" namespace
    Appsignal.Span.set_namespace(Appsignal.Tracer.root_span(), "critical")

    # The actual worker code
  end
end

It's also possible to configure the namespace when creating a transaction. Please see the documentation for decorators or instrumentation helpers on how to configure a namespace.

A note on helper location

The set_namespace helpers used in this guide can be called in any action that starts an AppSignal transaction. We recommend calling this as early in the request or background job as possible, so the transaction is configured with the given namespace before any error occurs. Otherwise, if an error occurs—or anything else that stops the process—the transaction is sent to AppSignal before the set_namespace code is called and it is reported under the default namespace instead.

Read more

• Appsignal.Transaction.set_namespace helper method documentation
• Elixir namespace decorator
• Elixir namespace instrumentation helper

Node.js

In Node.js applications AppSignal works with Spans to track metadata such as which namespace a Span belongs to. The namespace can only be set on the "root span", or the first span that's created without any parent spans. All children of this Span will inherit the namespace of the parent Span. When creating this root span, pass in the namespace option as a key with a String value that is the desired namespace name.

In a scenario where the Node.js http integration is not used and you need to create your own RootSpan (for example, in a worker or CLI tool), a RootSpan can be given a custom namespace like this:

const tracer = appsignal.tracer();
const span = tracer.createSpan({
  namespace: "custom-namespace", // a custom namespace for this span (defaults to `web`)
});

For more information, read more about how Spans work in Node.js.

JavaScript

In front-end JavaScript applications AppSignal works with spans to track metadata such as which namespace a span belongs to. The namespace can only be set on the "root span", or the first span that's created without any parent spans. When creating this root span, pass in the namespace option as a key with a String value that is the desired namespace name.

const span = appsignal.createSpan();
span.setNamespace("admin"); // a custom namespace for this span (defaults to `frontend`)

For more information, read more about how spans work in Front-end JavaScript.

Deploy

After the app has been configured with the namespace helpers, commit your changes and deploy the app. When the app starts/restarts, AppSignal will report the actions under the new namespace. Data from older deploys, grouping actions under their original namespaces, is not moved to the new namespace location.

Are namespaces not being reported or incorrectly? Contact us and we will help you out!
